Anchorage Buoy
What is an anchorage buoy?
An anchorage buoy is a buoy that marks the outer limits of designated anchorage areas. It’s colored yellow with a black anchor on it, because an anchorage buoy marks the perimeter of anchorage areas, consult a chart for water depth. If it carries a light the light is yellow and it will flash once every 4 seconds.
The aids to navigation are devices or systems that are within the pleasure craft’s environment; they warn the operator of dangers or obstructions; like shallow water. The navigational aids are provided to help the operator of a pleasure craft determine his/her position and course, and advise the operator of what is the best or preferred route to take.
There are a variety of things we can use to find our way around on the water. Known landmarks such as the mouth of a river or an island certainly help. In addition to these natural landmarks we have lighthouses, buoys, and beacons known collectively as aids to navigation or ATON for short.
Some of the most of these aids are the familiar channel markers or buoys. Each one will have unique characteristics so that it cannot be mistaken for something else. These characteristics include color, shape, and number or lettering displayed on them. In the US we use the lateral system meaning that the sides of channels are marked. When entering a harbor our rule of thumb is always: Red Right Returning.
We are returning whenever we enter a smaller body of water from a larger body. Mariner’s will often say this as: Leave the red buoys to starboard when returning. In other words, we pass by the buoy while keeping it on our right-hand side.
There is another convention also used. The numbers on buoys increase as we travel toward a harbor or smaller body of water. Also, all green buoys are odd numbered and reds are even numbered. So, we start at the entrance to a channel with #1 green to port (left) and #2 red on the starboard (right). These numbers will increase the further we go along.
There are basically four different types of buoys we might encounter in US waters: Red, green, red and green horizontally striped, and red and white vertically striped. We will talk about special buoys further below. Each one may or may not have a light. The light color will be green, red, or white.
Lights are often used where greater caution must be exercised such as a bend or narrowing of a channel. Also, especially in areas where fog may exist, some buoys make sounds such as a whistle, bell, or gong.
Green and red buoys. The greens will mark the port (left) side of a channel when entering a smaller body of water (returning) and reds mark the starboard (right) side while returning. The greens and reds come in two varieties; They can be lighted as above or they can be unlighted as below. An unlighted green buoy is called a can because of its flat top and an unlighted red is called a nun because of its pointed top resembling a nun’s cap. Greens and reds will have numbers on them and all other buoys will have letters.
Red and green horizontally striped buoys. These are junction buoys which also might indicate an obstruction with two different ways around the obstruction. These buoys will indicate the preferred and secondary channel to be taken. By studying the chart in advance you will be able to determine which channel you want to take.
Here is the rule to follow: The top band indicates the preferred channel. If you want the preferred channel, then simply read the top color of the buoy and ignore the lower color altogether. So, if the top color is red, you are returning, and you want the preferred channel; read the junction buoy as a solid red buoy and leave it to starboard. However, if you have decided that you want the secondary channel you would read the second color down from the top (green) and treat the buoy as a solid green leaving it to port when returning.
Red and white vertically striped buoys. These are safe water or mid-channel buoys indicating the good depth of water all around. They may be left to either side when returning or leaving. The entrance to major seaports is often marked with a sea buoy that is red and white vertically striped. This sea buoy is so called because it is the first buoy of the port that one would pass by, it is further out than even the first red and green buoys. These buoys are not numbered but will often have a letter(s). When used as a sea buoy they will have a letter that stands for the channel leading into that particular port. The sea buoy for Miami has a ‘M’ on it. Other safe water, mid-channel buoys may be small and round simply marking the middle of a channel. The rule for red and white vertically striped buoys is good water, leave it to either side.
Yellow buoys. Yellow represents caution on these buoys. Usually meaning to stay away from them. They are used to indicate pipes, dredge lines, traffic schemes, an isolated danger. They do not usually indicate which side to leave them on. Reading the chart may tell you their significance if they are marking a permanent hazard such as a shoal area. Yellow buoys, if lighted, will flash a yellow light. The rule for yellow buoys: Stay away. Special note on the meaning of the color yellow: While yellow means caution on these buoys yellow is also the designated color for identifying Intracoastal aids to navigation. As we will see later, all buoys and other aids on the Intracoastal Waterway will have at least some yellow on them.
Daybeacons. In shallow water, channels are often marked with a piling that has been driven into the mud bottom and topped with a daymark also called a dayboard. These use the same colors, lights, and numbering system as buoys.
Red and green daymarks. The red daymarks will be triangular, red, and even numbered while the greens will be square, green, and odd numbered. The chart symbol for the red is a triangle and for green is a square.
You may notice the symbols for lighted daybeacons are different than for buoys. As you will recall lights for buoys are indicated by a solid circle of magenta (purple) but here the lights are indicated by tear drop shapes of magenta (purple).
The general rule about lights on NOAA charts is if the navigation aid is floating then the chart symbol will be a circle; if the aid is attached to land (either by a pile or on solid land as in a lighthouse) its light will be indicated by a tear drop shape.
Red and green horizontally striped daybeacons. These are preferred channel (junction) daybeacons and used just like their counterpart buoys.
Red and white vertically striped daybeacons. These are octagonal shaped and mean safe water or mid-channel and can be passed safely to either side. They are direct counterparts to the red and white vertically striped buoys. The chart symbol for these daybeacons is a white square with the letter “A” in quotation marks. These may have lights and, if so, it would be white and flash Mo (A). This is Morse code “A” or; one short flash followed by a longer flash. The sequence would repeat after an interval of a few seconds.
Intracoastal Waterway Aids. The Intracoastal Waterway (also known as the ICW) runs just inside and parallel to the east and gulf coasts of the US. Since this waterway never leaves smaller bodies of water or returns from larger bodies of water we use the aids in a slightly different way. All red buoys and daybeacons are on the mainland side of the Intracoastal while all green buoys and daybeacons are on the ocean/gulf side of the Intracoastal. This arrangement is consistent throughout the waterway so we can remember like this: Red means stop, on the mainland side of the Intracoastal is dry land; don’t go there. Green means go, on the ocean side of the Intracoastal is deep water. Since the Intracoastal has landed, albeit a relatively narrow strip, between it and the ocean the analogy is only partially correct but works for many to remember the arrangement of buoys.
Yellow is the color used on the Intracoastal Waterway to distinguish the buoys and daybeacons so they won’t be confused with the red right returning buoys of a channel that crosses the Intracoastal.
Whenever you see a small swatch of yellow on a green or red buoy you know you’re on the Intracoastal. The only problem with this is that often the yellow has become faded due to the sun or has disappeared behind bird guano.
Light phase characteristics. Lights displayed by buoys, beacons and lighthouses come in a wide variety to facilitate identification. For instance, two red lighted buoys, close to each other in a channel, will need to flash at different rates so they can be identified at night.
How to rent an anchorage buoy?
When boating in South Lake Tahoe, you must get the best supplies and that’s why we refer to one important item that is known as an anchorage buoy; certainly used for anchoring.
There are several small marinas around the lake, as well as the huge Tahoe Keys marina at South Lake Tahoe. Slips are a precious commodity, however, and generally, are not available except for full-season rentals–and even then, waiting lists are often years long. Most marinas also provide a variety of services.
BJ’s Barge Service is a supply shop that carries hundreds of accessories for any type of water sport or boating adventure, including but not limited to wakeboards, wakesurfs, wakeskates, life jackets, tubes of all sizes, tow ropes, wetsuits, boardshorts, sandals, bikinis and cover up’s, fenders, waxes, dock lines, buoy lines, anchors, flares, air horns, and much more. You can find this place in Homewood; a city located near South Lake Tahoe.
